Wet Granulators

Wet Granulators
Products

Wet Granulators

These series of granulators has been designed to efficiently handle the simultaneous grinding and pre-washing of contaminated plastic materials collected from post-consume. By incorporating water into the process, these machines effectively remove significant amounts of impurities during operation, combining material reduction and pre-washing into a single step, thus saving time and resources. Durability and robustness are ensured by a structure built to withstand the most conditions. The rotor, made from a single block of steel and completely free of welds, is nickel coated to provide superior protection against rust and abrasion, ensuring long operational life. Internal components, such as the blade holders and grinding chamber, are also nickel coated to resist corrosion and abrasive agents. The easy replacement of these wear-prone parts makes these machines highly reliable and ideal for processing challenging and abrasive materials.

Rotor diam. 500/1000

Features and Advantages

  1. Simultaneous grinding and pre-washing
  2. Robust and wear-resistant construction
  3. Reduced energy consumption
  4. Ease of maintenance
Wet Granulators

TYPE BLADES MOUTH HOURLY OUTPUT ROTOR DIAM. MOTOR DIMENSIONS WEIGHT
D-6 WET 600 mm 600X700 mm 150/800 kg./H 500 mm 30-75 HP 2.000X1.100 mm 3.500 Kg
AD-9 WET 900 mm 900X800 mm 150/1.500 kg./H 500 mm 60-100 HP 2.000X1.300 mm 5.000 Kg
AD-12 WET 1.200 mm 1.200X800 mm 150/2.500 kg./H 500 mm 75-125 HP 2.000X2.100 mm 7.500 Kg
AD-15 WET 1.500 mm 1.500X800 mm 200/4.000 kg./H 500 mm 100-125 HP 2.300X2.300 mm 8.500 Kg
G-9 WET 900 mm 1.200X920 mm 700/3.000 kg./H 1.000 mm 150 HP 3.000X1.500 mm 12.000 Kg
G-12 WET 1.200 mm 1.200X1.200 mm 1.000/4.000 kg./H 1.000 mm 150 HP 3.000X1.700 mm 12.800 Kg
G-15 WET 1.500 mm 1.500X1.200 mm 1.000/5.000 kg./H 1.000 mm 180 HP 3.000X2.200 mm 14.100 Kg
G-18 WET 1.800 mm 1.800X1.200 mm 1.000/6.000 kg./H 1.000 mm 220 HP 3.000X2.500 mm 16.000 Kg

Industry 4.0
Drained cochlea
Big-Bag Holder structure
